Barbed Wire
High-strength barbed wire available in single and double strand options, with galvanized or PVC-coated finishes. Designed for agricultural, industrial, and high-security perimeter protection.
Barbed Wire
High-strength barbed wire available in single and double strand options with galvanized or PVC-coated finishes, suitable for agricultural, industrial, and high-security perimeter protection.
Product Overview
Barbed Wire is a widely used security fencing material constructed with sharp steel barbs twisted around line wires. It provides an effective and economical solution for perimeter protection in agricultural, commercial, and high-security environments. Available in single or double strand structures, Barbed Wire offers excellent tensile strength and strong deterrence against intrusion.
Surface finishes such as galvanizing or PVC coating provide resistance to corrosion, weathering, and harsh outdoor environments, ensuring long service life and reliable security performance.
Types of Barbed Wire
Single Strand Barbed Wire
Lightweight and economical, suitable for general agricultural and boundary applications where moderate protection is required.
Double Strand Barbed Wire
Made from two line wires twisted together, offering higher tensile strength and superior resistance to cutting. Ideal for heavy-duty uses such as prisons, military zones, borders, and restricted areas.
Galvanized Barbed Wire
Zinc-coated for excellent corrosion resistance and long service life, suitable for long-term outdoor exposure.
PVC Coated Barbed Wire
Available in green, blue, yellow, and other colors. Provides weatherproof protection and improved aesthetics while maintaining strong security performance.
Wire Diameter and Barb Spacing
- Wire diameter: 1.6 mm to 2.5 mm (BWG 12–15)
- Barb spacing: 3", 4", 5", 6" (76–150 mm)
Specifications
- 12 × 12 BWG: 6.0–7.6 m per kg depending on barb spacing
- 13 × 14 BWG: 8.8–10.7 m per kg depending on barb spacing
- 15 × 15 BWG: 13.8–17.5 m per kg depending on barb spacing
- Other gauges available upon request
Features of Barbed Wire
- Sharp barbs provide strong deterrence against intruders
- High stability, rigidity, and tensile strength
- Excellent resistance to acid, alkali, corrosion, and harsh climates
- Available in single twisted, double twisted, and traditional twisted patterns
- Long-lasting performance with minimal maintenance
Applications
Barbed Wire is widely used in:
- Farm fencing and grassland protection
- Orchards, gardens, and livestock boundaries
- Railways, highways, and transportation facilities
- Airports and national defense zones
- Prisons, military areas, and restricted sites
- Private property boundaries and perimeter security
It is often combined with chain link fences or welded mesh panels to enhance security and reduce intrusion.
Packing Information
Barbed Wire is supplied in coils, wrapped with plastic film inside and hessian or woven bags outside to ensure safe handling, storage, and transportation.
Detailed Specification Table
| Wire Diameter (BWG) | 3” Barb Spacing (m/kg) | 4” Barb Spacing (m/kg) | 5” Barb Spacing (m/kg) | 6” Barb Spacing (m/kg) |
|---|---|---|---|---|
| 12 × 12 | 6.06 | 6.75 | 7.27 | 7.63 |
| 12 × 14 | 7.33 | 7.90 | 8.30 | 8.57 |
| 12.5 × 12.5 | 6.92 | 7.71 | 8.30 | 8.72 |
| 12.5 × 14 | 8.10 | 8.81 | 9.22 | 9.562 |
| 13 × 13 | 7.98 | 8.89 | 9.57 | 10.05 |
| 13 × 14 | 8.84 | 9.68 | 10.29 | 10.71 |
| 13.5 × 14 | 9.60 | 10.61 | 11.47 | 11.85 |
| 14 × 14 | 10.45 | 11.65 | 12.54 | 13.17 |
| 14.5 × 14.5 | 11.98 | 13.36 | 14.37 | 15.10 |
| 15 × 15 | 13.89 | 15.49 | 16.66 | 17.50 |
| 15.5 × 15.5 | 15.34 | 17.11 | 18.40 | 19.33 |
