Palisade Fence

High-security steel palisade fence with D and W profiles, multiple pale head options, and hot-dip galvanized or powder-coated finish. Ideal for industrial, commercial, and public perimeter protection.

Product Overview

Palisade Fence is a high-security steel fencing system constructed from strong vertical pales fixed to horizontal rails and posts. It is available in both D-section and W-section profiles and can be supplied with pointed, rounded, or triple-pointed tops to effectively deter climbing and intrusion.

Standard heights typically range from 1.8 m to 3.6 m, with hot-dip galvanized or powder-coated finishes for excellent corrosion resistance and long service life. Palisade fencing is widely used for industrial sites, warehouses, schools, railways, airports, highways, government facilities, and utility plants, providing a durable, anti-climb, and highly effective perimeter protection solution.

Material & Processing

Palisade Fence is manufactured from high-quality steel sheet, hot-dip galvanized steel, cold-rolled steel, or hot-rolled steel. The surface treatment can be hot-dip galvanizing, powder coating, or PVC coating, providing outstanding corrosion resistance and long-term durability in outdoor environments.

Types of Palisade Fence

D Type Palisade Fence

• Thickness: 3.0 mm (general), 3.5 mm (security), 4.0 mm (special)
• Common height: 1.2–3.0 m
• Panel width: 1.8–2.35 m

W Type Palisade Fence

• Thickness: 2.0 mm (general), 2.5 mm (security), 3.0 mm (special)
• Common height: 1.8–2.4 m
• Panel width: 1.8–2.35 m

Pale Head Options

Palisade pales can be supplied with different head designs to match security levels and aesthetic requirements:

• Square top
• Single pointed
• Triple pointed
• Round top
• Round & notched top

Triple-pointed pales are commonly used in high-security sites to strongly discourage climbing and unauthorized access.

Panel Specifications

• Standard panel width: 2.75 m
• Each panel consists of 17 pales with D or W profile
• Fixed with 8 mm bolts and nuts
• Available heights: 1.2 m, 1.5 m, 1.8 m, 2.0 m, 2.1 m, 2.4 m, 3.0 m
• Pale thickness: 2.0 mm – 4.0 mm depending on type and security level

Key Features

• High strength and rigidity with anti-climb design
• Excellent corrosion resistance with galvanizing or powder coating
• Multiple RAL color options for decorative and corporate integration
• Easy to transport and install, suitable for uneven terrain
• Can be fitted with barbed wire or razor wire for enhanced perimeter protection

Applications

Palisade Fence is widely applied in:

• Factories and warehouses
• Airports and railway facilities
• Highways and transportation hubs
• Schools and residential communities
• Government and municipal buildings
• Military sites and power stations
• Utility plants and industrial perimeters

It provides excellent perimeter security while maintaining a modern, professional, and uniform appearance around high-value properties.
