Chain Link Fence

Durable and cost-effective chain link fence made from galvanized or PVC-coated wire, suitable for residential, commercial, and industrial perimeter protection.

Product Overview

Chain Link Fence, also known as cyclone fence, is one of the most widely used fencing solutions for residential, commercial, and industrial applications. It is valued for its durability, cost-effectiveness, and ease of installation. Made from galvanized or PVC-coated iron wire, chain link fencing offers excellent corrosion resistance and long-term performance.

With uniform zinc coating, precise mesh structure, and compliance with ASTM A-641 standards, Chain Link Fence is suitable for sports fields, playgrounds, farms, grasslands, factories, roadsides, power stations, warehouses, parks, and temporary construction barriers. It is a versatile fencing solution for both permanent and temporary projects. :contentReference[oaicite:1]{index=1}

Material & Surface Treatment

• Galvanized wire
• PVC coated wire
• PVC sprayed
• Electric galvanized
• Hot-dipped galvanized

Specifications

Mesh Opening

• 20 × 20 mm
• 40 × 40 mm
• 50 × 50 mm
• 60 × 60 mm
• 75 × 75 mm
• 80 × 80 mm
• 100 × 100 mm

Wire Diameter

• 1.0–6.0 mm (general range)
• Common sizes: 2.0 mm, 2.5 mm, 3.0 mm

Fence Dimensions

• Mesh height: 0.5 m – 6 m
• Roll length: 4 m – 50 m (Common: 5 m, 10 m, 15 m)
• Fence height options: 1.0 m, 1.2 m, 1.5 m, 1.8 m, etc.

Post Options

• Round post
• Angle iron post

Post & Rail Diameter

• 32 mm, 42 mm, 50 mm, 60 mm, 76 mm, 89 mm

Post & Rail Thickness

• 1.5 mm, 2.0 mm, 3.0 mm, 4.0 mm, 5.0 mm

Accessories

• Flat Iron: Fence support
• Brace Band: Connects tensioner and post
• Tension Band: Links flat iron and post
• Tensioner: Secures line wire
• Line Wire: Used for folding and reinforcing chain link mesh

Features

• Flexible mesh width and height; maximum height can exceed 5 m
• Dense diamond mesh design prevents climbing
• Portable and cost-saving post system
• Highly corrosion resistant and durable
• Easy to install, handle, and store
• Suitable for large-scale fencing projects

Manufacturing Process

Chain link fencing is produced using automated weaving machines that ensure uniform mesh opening and consistent wire tension. Our factories are equipped with high-capacity machinery capable of producing up to 30 tons within 10 days, ensuring fast delivery even for large orders. :contentReference[oaicite:2]{index=2}

Applications

Chain Link Fence is widely used for:

• Playgrounds and sports fields
• Factories and industrial perimeters
• Farms, grasslands, and animal enclosures
• Roadside fencing and construction sites
• Residential yards, gardens, and dog kennels
• Power stations, warehouses, and parking areas
• Temporary event or construction barriers
