Razor Barbed Wire
High-security razor barbed wire made from galvanized or stainless steel with sharp blades, available in concertina coils, flat wrap, and straight-line types for military and perimeter protection.
Razor Barbed Wire
High-security razor barbed wire made from galvanized or stainless steel with sharp blades, available in multiple coil and blade types for military, industrial, and perimeter protection.
Product Overview
Razor Barbed Wire, also known as concertina wire or barbed tape, is a high-security fencing material constructed from galvanized or stainless steel with extremely sharp blades designed to deter intrusion. It is available in several structures including single coil, concertina (cross type), flat wrap, straight-line, spiral, and rapid-deployment systems.
With coil diameters typically ranging from 450 mm to 980 mm, Razor Barbed Wire provides strong physical and psychological protection, making it an ideal solution for military bases, prisons, airports, factories, borders, government buildings, and private properties. Its corrosion resistance, durability, and quick installation ensure long-term and effective perimeter security.
Types of Razor Barbed Wire
Single Coil Razor Barbed Wire
Standard coil structure offering economical high-security performance.
Concertina Razor Wire (Cross Type)
Two coils clipped together at intervals to create an expanding accordion shape with strong deterrence.
Triple Strand Razor Wire
Enhanced multi-strand defense structure for extremely high-security zones.
Welded Razor Wire Mesh
Razor strips welded into mesh panels for flat surface installation where coils are not practical.
Rapid Deployment Razor Wire System
Pre-assembled defensive barriers for quick installation in military or emergency applications.
Blade Specifications
Common blade types include BTO (Barbed Tape Obstacle) and CBT (Concertina Barbed Tape):
- BTO-12: 12 mm barb length, 26 mm spacing
- BTO-22: 22 mm barb length, 34 mm spacing
- BTO-30: 30 mm barb length, 45 mm spacing
- CBT-60: 60 mm barb length, 100 mm spacing
- CBT-65: 65 mm barb length, 100 mm spacing
Standard wire diameter: 2.5 mm Blade thickness: 0.5–0.6 mm
Coil Sizes and Lengths
- Coil diameters: 450 mm, 500 mm, 600 mm, 700 mm, 800 mm, 960 mm
- Single coil: 8–13 m per coil depending on diameter
- Cross type coil: 9–16 m per coil depending on loops and diameter
Features of Razor Barbed Wire
- Strong deterrence due to extremely sharp blades
- Corrosion resistance with galvanized or stainless steel materials
- Fast installation in coil or mesh form
- Effective physical and psychological barrier
- Suitable for both permanent and temporary fencing
Applications
Razor Barbed Wire is widely used for:
- Military facilities and defense perimeters
- Prisons, detention centers, and high-risk compounds
- Border security and restricted areas
- Government buildings and public security sites
- Factories, warehouses, villas, and private property protection
- Highways, railways, and airport fencing
Standard Coil Specifications
| Outside Diameter | No. of Loops | Standard Length per Coil | Type | Notes |
|---|---|---|---|---|
| 450 mm | 33 | 7–8 m | CBT-60/65 | Single coil |
| 500 mm | 56 | 12–13 m | CBT-60/65 | Single coil |
| 700 mm | 56 | 13–14 m | CBT-60/65 | Single coil |
| 960 mm | 56 | 14–15 m | CBT-60/65 | Single coil |
| 450 mm | 56 | 8–9 m | BTO-12/22/25/30 | Cross type |
| 500 mm | 56 | 9–10 m | BTO-12/22/25/30 | Cross type |
| 600 mm | 56 | 10–11 m | BTO-12/22/25/30 | Cross type |
| 600 mm | 56 | 8–10 m | BTO-12/22/25/30 | Cross type |
| 700 mm | 56 | 10–12 m | BTO-12/22/25/30 | Cross type |
| 800 mm | 56 | 11–13 m | BTO-12/22/25/30 | Cross type |
| 900 mm | 56 | 12–14 m | BTO-12/22/25/30 | Cross type |
| 960 mm | 56 | 13–15 m | BTO-12/22/25/30 | Cross type |
| 980 mm | 56 | 14–16 m | BTO-12/22/25/30 | Cross type |
Blade Dimension Table
| Reference | Thickness | Wire Diameter | Barb Length | Barb Width | Barb Spacing |
|---|---|---|---|---|---|
| BTO-10 | 0.5±0.05 | 2.5±0.1 | 10±1 | 13±1 | 26±1 |
| BTO-12 | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 |
| BTO-18 | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 |
| BTO-22 | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 34±1 |
| BTO-28 | 0.5±0.05 | 2.5 | 28 | 15 | 45±1 |
| BTO-30 | 0.5±0.05 | 2.5 | 30 | 18 | 45±1 |
| CBT-60 | 0.5±0.05 | 2.5±0.1 | 60±2 | 32±1 | 100±2 |
| CBT-65 | 0.5±0.05 | 2.5±0.1 | 65±2 | 32±1 | 100±2 |
